One of JinJue V-Bank Filter Hospital Grade’ key features is its remarkably quiet operation, coupled with stable and reliable performance, meeting the H14 level of efficient filtration standards. Not only does it effectively prevent the growth of bacteria, viruses, and other microorganisms on the surface of purification materials, but it also efficiently prevents secondary pollution, providing a safer and healthier air quality guarantee for medical and laboratory environments.
V-Bank Filter Hospital Grade Advantages:
1.Quiet Operation
2.Stable Performance
3.Energy Efficient and Environmentally Friendly
4.PU Gaskets and Protective Nets on Both Sides
Detailed information：
Item name:V-Bank Filter Hospital Grade
Type: V-bank (3V, 4V, 5V), box type
Frame material: ABS, SUS304, Wood, Anodised extruded aluminum
Filter media: PTFE (Polytetrafluoroethylene) membrane
Gasket: PU gasket on both sides
Filter class: HEPA filters (H13/H14)
Initial resistance: ~50% lower than glass fibre
Standard size: 592 x 592mm, 490 x 592mm
Standard depth: 292 / 300 / 400 / 435mm
Material & Working Conditions:
|
Filter Media
|
Micro glass fiber, PP
|
|
Frame Material
|
ABS + PVC
|
|
Sealant
|
Polyurethane
|
|
Gasket
|
EVA,EPDM
|
|
Separator
|
Hot melt Glue
|
|
Standard Frame Size
|
292,296,330,400,435
|
|
Max. Working Temperature
|
70℃
|
|
Max. Working humidity
|
100%
|
Technical datasheet
|
No.
|
Width
|
Height
|
Depth
|
V
|
Flange Size
|
Note
|
|
287
|
287/490/592/610
|
292
|
2
|
25
|
|
|
490
|
287/490/592/610
|
292
|
3
|
25
|
|
|
592
|
287/490/592/610
|
292
|
3
|
25
|
|
|
594
|
292/594
|
292
|
3
|
20
|
|
|
592
|
287/490/592/610
|
292
|
4
|
25
|
|
|
592
|
287/490/592/610
|
400
|
4
|
25
|
|
|
592
|
287/592
|
292
|
4
|
19
|
Wide-Body
|
|
592
|
592
|
435
|
4
|
20
|
|
|
590
|
287/592
|
292
|
4
|
20
|
|
|
592
|
287/490/592/610
|
292
|
4
|
25
|
Four Sides Sealed
|
|
592
|
287/490/592/610
|
292
|
5
|
25
|
|
|
610
|
287/490/592/610
|
292
|
5
|
25
|
|
|
592
|
592
|
330
|
5
|
20
|
Arc Shaped
|
|
610
|
305/610
|
292
|
4
|
-
|
Box type
|
|
610
|
305/610
|
292
|
6
|
-
|
Box type
|
Note: Customized V-Bank Filter Hospital Grade Available (need to make mold first)
Product Details
