Suction Filter can suck liquid and solid particles together and send them to the filter net for screening and filtering. Since no additional equipment such as additional pumps is required, the operation is convenient, intuitive and simple. Therefore, the suction filter can significantly improve production efficiency and save time and labor costs. This equipment is also suitable for more demanding industrial environments, such as pharmaceuticals, food, chemicals and various liquid processing fields. It can filter suspended particles more finely to ensure the purity and safety of materials.
There are many commonly used filter materials in Suction Filter, such as PP, UPE, PE, PA, PES, PTFE, metal mesh, etc. The applicable scope of each material is different, and it needs to be selected according to the actual situation when using it.
Some Parameters of Suction Filter
|
Internal and external surface treatment
|
polishing/sandblasting/painting
|
|
Polishing
|
Inner surface Ra ≤ 0.6 μ m, outer surface Ra ≤ 0.8 μ m
|
|
Sandblasting/painting
|
inner surface Ra ≤ 0.6 μ m, outer surface sandblasting/painting
|
Material of Suction Filter
|
Filter housing
|
SUS304, SUS316L,Carbon steel,2205 stainless steel
|
|
Exhaust&Discharge&Pressure Gauge
|
SUS304, SUS316L
|
|
Quick installation bolt group
|
SUS304
|
|
Support
|
SUS304, carbon steel
|
|
Gasket
|
Silicone, fluororubber, EPDM, PTFE, fluorine coated
|
|
Note: (Carbon steel material surface does not undergo polishing treatment)
|
Operating Conditions of Suction Filter
|
Design pressure
|
Working temperature
|
|
≤ 0.6Mpa
|
≤90 ℃
|
Connection Form of Suction Filter
|
Barrel connection
|
Quick installation bolt group
|
|
Import and export
|
Flange/quick fit chuck
|
|
Exhaust valve
|
G1/2”
|
|
Drainage valve
|
G1/2”(Determined by the number of cores)
|
|
Pressure gauge
|
M14 * 1.5/Quick fit chuck/flange
|
Selection Table of Suction Filter
|
Number of filter elements
|
Filter bag model
|
inlet and outlet connection method
|
inlet and outlet size
|
filter material
|
filter element interface type
|
sealing ring
|
Form
|
|
01
|
Bag 1 (1)
|
Flange F/chuck K
|
32
|
SUS304（T）
|
Steel ring (G)
|
Silicone (S)
|
Spray coating（PT）
|
|
Bag 2 (2)
|
|
|
SUS316L(S)
|
Plastic ring (P)
|
Fluorine glue (V)
|
|
|
Bag 3 (3)
|
|
|
Carbon steel (C)
|
Tie rope (S)
|
EPDM (E)
|
|
|
Bag 4 (4)
|
|
|
|
|
Nitrile (D)
|
|
|
Bag 5 (5)
|
|
|
|
|
|
|
Selection table
|
Number of filter elements Filter
|
element length
|
Inlet and outlet size
|
Inlet and outlet size
|
Filter material
|
Filter element interface type
|
Sealing ring
|
form
|
|
01
|
Bag No. 1（1）
|
Flange F/Chuck K
|
32
|
SUS304（T）
|
Steel Rims(G)
|
Silica gel(S)
|
（PT）
|
|
Bag No. 2 （2）
|
|
|
SUS316L(S)
|
Plastic ring(P)
|
Fluorine rubber（V）
|
|
|
Bag No. 3（3）
|
|
|
Carbon Steel（C）
|
Rope（S）
|
EPDM（E）
|
|
|
Bag No. 4（4）
|
|
|
|
|
Nitrile（D）
|
|
|
Bag No. 5（5）
|
|
|
|
|
|
|
