The oil filter comprises a special gear pump driven by a motor, which has the characteristics of low noise, strong self-priming ability and stable operation. The high-pressure pipeline isequipped with overflow protection device, which can effectively protect the safety ofthe hydraulic system.
Rated flow rate L/min 25 32 40 50 63 100 150
Rated pressure MPa 0.6
Origin al pressure loss MPa ≤0.02
Coarse fltration accuracy pm 100
Grade 1 Fine Filtration Accuracy um 10、20、40
Level 2 precision filtration um 3、5、10、S-W
Riter replacemenpressure dimerenice Mpa 0.2
Operating temperture 5-80
Recommended viscosity cSt 10-160
Powerscoy AV380V Three Phase 50 Hz
Electric power kw 0.55 0.75 1.1 1.1 1.5 2.2 3.0
Weight kg 46 78 90 96 102 120 160
External
dimensions mm LxBxH 520x350 x950 520x350 x950 720x680 x1020 720x680 x1020 720x680 x1020 720x750 x1020 720x750 x1020
Filter element: Select high-precision filter material,large filter area follow the international advanced level of structural design. Connection:Hydraulic pipe jointreliable connection and seal,zero leakage. Oil pan: helps to keep the workplace safe and clean.
Filter element: Select high-precision filter materia,large filter area follow the international advanced level of structural design. Connection:Hydraulic pipe jointreliable connection and seal,zero leakage Oil pan:helps to keep the workplace safe and clean.
